Pre-operation checks

Make sure that the battery is securely held in
place.
EJU32614
Steering system checks
Turn the handlebars to the right and left sev-
eral times to make sure that operation is
smooth and unrestricted throughout the
whole range, and that the free play is not ex-
cessive.

Difference between fully turned posi-
tions of jet thrust nozzle (distances A
and B):
Maximum 5 mm (0.20 in)

EJU32636
Reverse system checks (EX SPORT)
EWJ00032

Do not touch the reverse gate while the
Turn the handlebars as far as possible to the
shift lever is being operated, otherwise
right and left to make sure that the jet thrust
you could be pinched.
nozzle moves as the handlebars are turned,
and that there is no difference between the Operate the shift lever several times to make
right and left fully turned positions of the jet sure that operation is smooth throughout the
thrust nozzle. whole range. Also, make sure that the reverse
gate moves up and down according to the
operation of the shift lever and that the gate
makes contact with the stoppers. (See page
34 for reverse system operation.)
