Instrument operation

other display segments of the information
1
display turn off. If the battery voltage has ris-
en significantly, “HI” is displayed. If “Lo” or
“HI” is displayed, immediately return to shore
and have a Yamaha dealer service the water-
craft.
1

1 Hour meter and voltmeter
TIP
If the engine is stopped after the check en-
gine warning is activated, the hour meter and
error code will be displayed alternately at 3-
second intervals.
1 Voltmeter
Hour meter EJU37272
The hour meter shows the total number of Fuel level meter
hours that the engine has been running since The fuel level meter shows the amount of fuel
the watercraft was new. remaining in the fuel tank. The amount of re-
maining fuel is shown using four display seg-
1 ments, which disappear one at a time as the
fuel level decreases.
TIP
The accuracy of the fuel level meter varies
depending on the operating conditions. Use
this function as a reference only.
1

1 Hour meter
TIP
The elapsed time will be kept even if the bat-
tery terminals have been disconnected.

Voltmeter
The voltmeter shows the battery voltage.
When the battery voltage is normal, the volt-
1 Fuel level meter
meter displays approximately 12 volts.
If the battery voltage has dropped significant-
ly, “Lo” is displayed on the voltmeter, and all

40
