Watercraft operation

squeezed, the reverse gate lowers and de-
flects the water jet being discharged from the 1
jet thrust nozzle so that the watercraft moves
in reverse or is in neutral. When the throttle le-
ver is squeezed, the reverse gate rises and
the watercraft moves forward.
TIP
 This model is equipped with a function
2
which limits the engine speed in reverse.
 When the engine is started, the reverse
1 Reverse gate
gate automatically moves to the neutral po-
2 Reverse position
sition.
To shift into reverse: 1
(1) Release the throttle lever.
(2) Squeeze the RiDE lever. The reverse
gate will lower, the engine speed will in-
crease, the watercraft will start moving in
reverse, and the “R” (reverse) shift indi-
cator will be displayed.

1
1 “R” (Reverse position)
To shift into neutral from reverse:
Release the RiDE lever. The reverse gate will
automatically return to the neutral position
and the “N” (neutral) shift indicator will be dis-
played.

1 RiDE lever
1

1 RiDE lever

35
