Instrument operation

Additional information EJU46673
Information such as the time or information Map screen “ ”
from a connected device is displayed in addi- Select “ ” on the screen tab bar to display
tional information. Select additional informa- the map screen.
tion to switch the displayed information.

10 FAST
MPH ACCEL 1 mi
PM
MPH
12.7 V MPH x1000 RPM
1
TIP
1 Additional information
 If a map card is not loaded, the map func-
Information that can be displayed in addition- tions will be limited. To load a map card,
al information is as follows. read the QR code displayed on the map
 Clock screen.
 Drive control mode setting information  If a GPS signal cannot be acquired, none of
 Status of connected devices the map functions will be available.
 Information for currently playing music
TIP Item Function
If none of these functions are turned on, ad- 1 mi Displays the map scale.
ditional information is not displayed. Displays north on the map at the top
of the screen.
Displays the course the watercraft is
cruising along.
Centers the map on the current loca-
tion of the watercraft.
Indicates the central region of the dis-
played map.
Opens the “ ”.
Zooms in or out on the map.
Indicates the position of the water-
craft.
TIP
 The symbol “ ” appears if the watercraft is
not displayed at the center of the map.
 You can also zoom in or out on the map us-
ing finger controls (pinch and spread).

51
