Instrument operation

EJU46880  “NAV AIDS”
Depth contour and safety contour settings
(“Depth/Position”) TIP
Set the “DEPTH CONTOUR” and “SAFETY If “TRACKS” is set to hide in the map display
CONTOUR” to change the depth contour settings, the track will not be displayed on the
and safety contour displayed on the map. map screen even if the track is set to
“Shown”.

EJU46903
Depth / Position Return to factory settings
(“ ”)
DEPTH CONTOUR
1 ALL 66ft 33ft 16ft 6ft OFF The settings can be reset to their factory de-
fault settings. The items that are reset and the
SAFETY CONTOUR default settings are as follows.
2 66ft 33ft 16ft 6ft OFF  PIN code
 Last maintenance time
 “ ” function setting information
1 “DEPTH CONTOUR”  Waypoint information
2 “SAFETY CONTOUR”
 Drive control mode information
Change the “DEPTH CONTOUR” value to  Auto trim information
change the display of the depth contour dis- To reset the settings:
played on the map. (1) Select “ ”.
The color of the water area displayed on the
map screen changes according to the value
Factory Reset
set in “SAFETY CONTOUR”.
TIP
RESET USER SETTINGS
 The deeper the depth, the lighter the color
of the water area. The shallower the depth,
RESET
the darker the color of the water area.
 When “SAFETY CONTOUR” is set to
“OFF”, the color of the water area is dis-
1
played in white.
1 “RESET”
EJU46890
Map display settings (“Chart Setup”) (2) After accepting the final confirmation
You can switch between showing and hiding message, select “ ”.
information displayed on the map screen. Se-
lect an item to switch between showing and
hiding the item. The following display infor-
mation can be switched.
 “GRIDS”
 “TRACKS”
 “WAYPOINTS”
 “WAYPOINT NAMES”

68
