Watercraft operation

This function can be used only when the wa-
tercraft is in neutral.
TIP
While the watercraft is shifted into forward,
the “TRIM/T.D.E.” switch controls the electric
trim system. (See page 37 for information on
the electric trim system.)
Activating and deactivating the T.D.E. 1
The activation of the T.D.E. can be confirmed
by the T.D.E. indicator on the multifunction 1 “TRIM/T.D.E.” switch
information center.
TIP
2 T.D.E. Forward While the T.D.E. is activated, the “N” (neutral)
shift indicator will be displayed and “0” will be
3 T.D.E. Reverse displayed on the speedometer.

To deactivate the T.D.E.:
MPH Perform one of the following operations. The
RPM
x1000
T.D.E. Forward T.D.E. indicator disappears and the T.D.E. is
deactivated.
10 :00 AM
12.7 V
 Squeeze the throttle lever.
1
1 T.D.E. indicator  Squeeze the RiDE lever.
 Push and hold the “CRUISE/NO WAKE”
2 Forward operation at a very low speed
switch.
3 Reverse operation at a very low speed
 While moving forward at a very low speed,
To activate the T.D.E.:
push the lower side of the “TRIM/T.D.E.”
(1) Shift into neutral. switch.
(2) Push the upper side of the “TRIM/T.D.E.”  While moving in reverse at a very low
switch to move forward at a very low speed, push the upper side of the
speed or push the lower side of the “TRIM/T.D.E.” switch.
“TRIM/T.D.E.” switch to move in reverse
TIP
at a very low speed.
The T.D.E. is also deactivated when the en-
gine is stopped.
EJU45911
No-wake mode
The no-wake mode is a function that main-
tains the engine speed at a fixed setting for
operating the watercraft at low speeds. While
the watercraft is operating in no-wake mode,
the engine speed can be adjusted to one en-

40
